DILM 32-10 Contactor

Professional-grade DILM series contactor engineered for reliable motor control in Virtus Equipment and ZERMA America machinery. Features 32A switching capacity with advanced contact technology for extended service life. Built to IEC standards with versatile mounting options and excellent switching performance under demanding industrial conditions.

SKU 80031642 Category Tags , , , , , , , ,

Description

The DILM 32-10 Contactor represents advanced motor control technology for Virtus Equipment and ZERMA America material processing systems. This precision-engineered contactor delivers reliable switching performance for medium to high-power applications, ensuring consistent operation and extended service life in demanding processing environments.

Additional information

Weight 1 lbs
Dimensions 4 × 2 × 5 in
Technical Specifications:
Part Number: DILM 32-10
SKU: 80031642
Main Contact Rating: 32A at 690V AC (AC-3 motor duty)
Contact Configuration: 3-pole main + 1 NO auxiliary
Coil Options: 24V, 110V, 230V AC/DC available
Mechanical Life: 10,000,000 operations minimum
Electrical Life: 2,000,000 operations (AC-3 duty)
Operating Temperature: -25?C to +60?C
Mounting: DIN rail, panel mount, or base mounting
Standards Compliance: IEC 60947-4-1, UL 508, CSA
Key Features:
32A Switching Capacity: Optimal for medium-power motor control applications
Advanced Contact Technology: Silver alloy contacts ensure reliable switching performance
IEC Standard Compliance: Built to international electrical standards
Versatile Coil Options: Available in multiple voltage configurations
Compact Design: Space-efficient installation in control panels
Applications: Critical for motor control on Virtus Equipment and ZERMA America processing equipment. Ideal for conveyor motors, blower fans, hydraulic pumps, and auxiliary drive systems requiring reliable medium-power switching capability.
