Description
The Safety Switch AZM16 ICC-12/12KK-24VDC represents advanced safety interlock technology from Schmersal, specifically designed for Virtus Equipment and ZERMA America material processing systems. This certified safety-rated switch with integrated control contact provides comprehensive machine guarding and operator protection, ensuring compliance with international safety standards while delivering reliable performance in demanding industrial applications.
Technical Specifications:
SKU: 80030023
Manufacturer: Schmersal
Part Number: AZM16 ICC-12/12KK-24VDC
Type: Coded safety interlock switch with integrated control contact
Series: AZM16 safety switch family
Coding: ICC-12/12KK coded actuator system
Operating Voltage: 24VDC
Contact Type: Positive-opening safety contacts plus control contact
Safety Rating: Certified to ISO 14119 and IEC 60947-5-3
Mounting: Panel or door frame mounting configuration
Protection Rating: Industrial-grade environmental protection
Diagnostic Features: Integrated monitoring and status indication
Key Features:
Certified Safety Rating: Meets international safety standards including ISO 14119 and IEC 60947-5-3 for machine guarding applications
Coded Actuator System: ICC-12/12KK coded key prevents unauthorized bypass and ensures high-security access control
Integrated Control Contact: Built-in auxiliary contact enables control circuit monitoring and equipment sequencing
24VDC Operation: Low-voltage DC operation compatible with modern PLC and control systems
Positive-Opening Contacts: Mechanically linked safety contacts ensure reliable disconnection meeting EN 1088 requirements
Diagnostic Capability: Advanced monitoring features enable fault detection and system health monitoring
Tamper-Resistant Design: High-security coded actuator prevents manipulation and unauthorized access attempts
Industrial Housing: Robust enclosure withstands harsh manufacturing environments and repeated operation
LED Status Indication: Visual feedback provides clear operational status and diagnostic information
Applications: Critical safety component for granulators, shredders, and material processing equipment used in plastic recycling, manufacturing scrap recovery, and waste processing operations. Essential for protecting operators by monitoring access doors, feed hopper positions, screen chambers, maintenance panels, and protective guards with certified safety interlock function. Ideal for recycling facilities, injection molding plants, extrusion operations, blow molding facilities, and manufacturing environments requiring certified safety interlocks with integrated control functionality for compliance with stringent occupational safety regulations. Perfect for applications where advanced safety features including coded access, diagnostic monitoring, and control contact integration are essential for equipment protection, operational safety, and automated system integration. Suitable for integration with safety PLCs and control systems requiring 24VDC safety circuit operation with diagnostic capability.
